자동차용 연동연선
AV Low Tension Cables
- ALow tension cables for automobile
- VPolyvinyl Chloride
- RATING
- 80℃
- APPLICATION
- Cable used in low voltage circuits in automobiles(vehicles and motorcycles)
- STANDARD
- JASO D611, ES SPEC
- MATERIAL
- Condductor : Annealed stranded copper
- Insulation : Polyvinyl Chioride
COMPOSITION
| Nomiral Size ㎟ |
Conductors | Insulation Thickness ㎜ |
Overall Diameter | Conductors resistance Ω/㎞ |
Approx weight ㎏/㎞ |
Stardard lenght m |
|||
|---|---|---|---|---|---|---|---|---|---|
| Construction No/㎜ |
Calculated area ㎟ |
Outer Diameter ㎜ |
Standard ㎜ |
Max ㎜ |
|||||
| 0.5 | 7/0.320 | 0.5629 | 1.0 | 0.6 | 2.2 | 2.4 | 32.7 | 9 | 100 |
| 0.5f | 20/0.180 | 0.5087 | 1.0 | 0.6 | 2.2 | 2.4 | 36.7 | 8 | 100 |
| 0.75f | 30/0.180 | 0.7630 | 1.2 | 0.6 | 2.4 | 2.6 | 24.4 | 12 | 100 |
| 0.85 | 11/0.320 | 0.8846 | 1.2 | 0.6 | 2.4 | 2.6 | 20.8 | 12 | 100 |
| 1.25 | 16/0.320 | 1.287 | 1.5 | 0.6 | 2.7 | 3.4 | 14.3 | 17 | 100 |
| 1.25f | 50/0.18 | 1.273 | 1.5 | 0.6 | 2.7 | 2.9 | 14.7 | 17 | 100 |
| 2 | 26/0.32 | 2.091 | 1.9 | 0.6 | 3.1 | 4.1 | 8.81 | 25 | 100 |
| 3 | 41/0.320 | 3.297 | 2.4 | 0.7 | 3.8 | 4.1 | 5.59 | 39 | 100 |
| 5 | 65/0.320 | 5.228 | 3.0 | 0.8 | 4.6 | 4.9 | 3.52 | 60 | 100 |
| 8 | 50/0.450 | 7.952 | 3.7 | 0.9 | 5.5 | 5.8 | 2.32 | 90 | 100 |
